Strong, durable slot drain with an unobtrusive finish
Gatic® Slot Drain handles everything from a raindrop to a rainstorm with almost the same high efficiency. Originally designed to meet the heavy demands of the world’s biggest ports and airports, this product has proven infinitely scalable and has been developed into a comprehensive range of products suitable for smaller projects such as landscaping schemes, shopping developments and parking facilities.
The IQ Flush Threshold Drain system provides a robust and effective water protection and drainage for flush threshold base frame details. The hidden drainage channel can take up to 90 litres of water per minute and the exposed metal grille is anti-corrosive – suitable for marine environments or in conjunction with a chlorine or salt water pool. Gatic® Slot Drain handles everything from a raindrop to a rainstorm with almost the same high efficiency. Originally designed to meet the heavy demands of the world’s biggest ports and airports, this product has proven infinitely scalable and has been developed into a comprehensive range of products suitable for smaller projects such as. Stainless Steel Slot Drains Favoured by landscape architects, our slot drain has been designed to offer a very discreet but highly effective channel drainage solution. The slot channels maximise flow capacity while minimising the profile visible at ground level, allowing it to fit within the surrounding area.
The unobtrusive design of Gatic’s slot drain means that it is aesthetically pleasing to the eye, is simple to install and benefits from reduced maintenance and installation costs.
Minimal visual impact
Slotdrain’s continuous intake slot is the only outward indication of the highly efficient surface water drainage system that lies just out of sight.
Easy & quick to install
Designed to keep below ground pipework to a minimum, thereby reducing installation time and both labour and materials costs.
Strong, durable & impact resistant
Initially designed to withstand the heavy demands of the world’s major airports and ports. This concept was then developed to suit smaller projects.
Comprehensive range
We supply a wide range of sizes and load bearing capacities making this product ideal for all kinds of applications, from residential, commercial and landscaping schemes to the most demanding of heavy industrial and transport projects.
Bespoke capability
If your project requirements can’t be achieved with our standard range of products or you have a particularly unusual problem to overcome, we can arrange the design and manufacture of custom components suit your needs.
Load rating from A15 to F900
Gatic Slotdrain channels are suitable for applications up to F900 (depending on the system type). The systems can handle everything from a raindrop to a rainstorm with similar efficiency.
Our range of products
Gatic Slotdrain comes in a comprehensive range to suit your specific requirements:
CastSlot
Designed specifically to meet the needs of supermarket car parks and delivery / distribution areas, where load ratings can reach F900.
The unobtrusive profile of CastSlot sits neatly within concrete, asphalt, and block surface finishes. CastSlot features an electro painted ductile iron throat section, which is securely fixed to the galvanised steel channel body to provide an exceptionally robust yet discreet drainage system. A treadsafe option is also available for areas where there is regular foot traffic. Available with a 10mm or 30mm opening. The NEW through spacer gives designers the flexibility to pass cables or other services through the channel throat as well as detail additional reinforcing for CastSlot and UltraSlot products. The new locking design ensures alignment and a tight fit prior to taping and pouring.
Load Classification: A15 to F900
Available channel widths:
High capacity surface water drainage
100mm, 150mm, 225mm, 300mm, 350mm, 400mm, 500mm, 600mm
UltraSlot
UltraSlot is used in external pavement areas which are subject to constant traffic, such as airports, ports and areas with heavy-duty vehicles.
The channel top edge has an outward fold for protection over the edge of the concrete encasement/surround, to prevent damage. Innovative channel features; concrete anchors, stabilising bars, channel feet and others, ensure the channel has a physical connection to steel reinforcing and is properly tied into the concrete encasement/surround, to create a strong, solid and durable structure.
A Treadsafe Bar can be fitted to the UltraSlot channel, which reduces the slot opening from 30mm wide to 2x9mm wide slots. This has no effect on the intake capacity of the system but will make the channel safe to cross when used in locations where pedestrians are walking over the pavement area. The NEW through spacer gives designers the flexibility to pass cables or other services through the channel throat as well as detail additional reinforcing for CastSlot and UltraSlot products. The new locking design ensures alignment and a tight fit prior to taping and pouring.
Load Classification: A15kN to F900kN
Available channel widths:
100mm, 150mm, 225mm, 300mm, 350mm, 400mm, 500mm, 600mm
PaveSlot
PaveSlot is used to drain external hard surface areas, where a neat, unobtrusive and aesthetic appearance is required. The system is typically used with paving units, laid against the top edge of the channel.
Throat spacer perforations allow any subsurface water that may have settled under paving units, besides the channel, to percolate and move into the channel body. The system is suitable for all paved areas, in public and commercial projects, which may be subject to occasional traffic by delivery and service vehicles.
Slot Drain Pan Ukulele Chords
Load Classification:
A15kN to C250kN
Available channel widths:
100mm, 150mm, 225mm, 300mm, 350mm, 400mm, 500mm, 600mm
FacadeSlot
A discreet surface drainage channel that can be installed directly against a building, wall or other external landscape feature, to provide effective drainage of surface liquids from vertical surfaces, door thresholds and the adjacent pavement area.
FacadeSlot channels can be made to follow the building perimeter whether straight or curved. The system can accommodate rainwater downpipes which, when positioned over a simple rainwater inlet box, can eliminate the need for a separate drainage network for the roof area, achieving a more efficient drainage design.
Load Classification: A15 (Bespoke units can be made which are suitable for up to D400)
Available channel widths:
50mm, 75mm, 115mm
Swarm Aqua – Revolutionary slot drain
With a strong, durable ductile iron top section, this slot drain system combines steel side walls & Twinwall conduit to make it the perfect solution for all external drainage applications.
Slot Drain Pan
ACO Qmax – Versatile & robust
Slot Drain Pan Uk Vhs
A versatile slot drain system that is designed to suit a wide range of applications, including small to large catchment areas as well as any load class. Another excellent slot drain choice.
